Overall Dimensions
Download
Cooperation| 吃瓜网 定子毗连体例 ( Winding Type ) | 星形 ( Star connection) |
| 霍尔造谣生事方面 ( Hall Effect Angle ) | 120度电偏角 ( Electrical Angle of 120 degree) |
| 径向裂缝 ( Radial Play ) | 0.02mm@450g |
| 心轴裂缝 ( Axial Play ) | 0.08mm@450g |
| 较大径向负载电阻 ( Max radial force ) | 28N 距法兰部10mm ( 10mm From the flange) |
| 更大载荷短路电流 ( Max axial force ) | 15N |
| 介电屈服强度 ( Dielectric Strength ) | 600VAC/1S |
| 绝缘层电阻功率 ( Insulation Resistance ) | 100MΩ, 500VDC |
| 情况发生湿度 ( Ambient Temperature ) | -20°C ~ +50°C |
| 接地等级 (Insulation Class) | Class B |
| 接外挂作弊技术参数Connector Model | Pin位Pin number | 效率Functions |
| Molex 2074790003 | Pin 1 | W相 ( Phase W ) |
| Pin 2 | V相 ( Phase V ) | |
| Pin 3 | U相 ( Phase U ) | |
| Molex 5023821270 | Pin 1 | 霍尔主机电源正 ( Vcc ) |
| Pin 2 | 商品代码器（ A-） | |
| Pin 3 | 编号器（ A+） | |
| Pin 4 | 商品代码器（ B-） | |
| Pin 5 | 识别码器（ B+） | |
| Pin 6 | 编码查询器 (Z-) | |
| Pin 7 | 数字器 ( Z+) | |
| Pin 8 | 霍尔 U ( Hu ) | |
| Pin 9 | 霍尔 V ( Hv | |
| Pin 10 | 霍尔 W ( Hw ) | |
| Pin 11 | 项目编码器接线防御系统线(PE) | |
| Pin 12 | 霍尔24v电源负 ( GND ) |
| 单 位 (Unit) | FL60BLW42-24V-37110A-EN | |
| 极数 ( Number of poles ) | 14 | |
| 相数 ( Number of phases ) | 3 | |
| 加倍端电压 ( Rated voltage ) | VDC | 24 |
| 格外扭矩 ( Rated torque) | mN.m | 290 |
| 持续时间高速运转惯量 ( Continuous stall torque) | mN.m | 348 |
| 加倍数率 ( Rated speed ) | RPM | 3500 |
| 格外吃瓜网 功率 ( Rated power ) | W | 106 |
| 阀值电动机扭矩 ( Peak torque ) | mN.m | 870 |
| 最高值电流值 ( Peak current ) | A | 17 |
| 线电容 ( Line to line resistance ) | ohms@20℃ | 0.23 |
| 线电感 ( Line to line inductance ) | mH | 0.22 |
| 转距常数 ( Torque constant ) | mN.m/A | 50 |
| 反电势 ( Back EMF ) | Vrms/KRPM | 4 |
| 运转惯量 ( Rotor inertia ) | g.cm2 | 1000 |
| 主机段长度 ( Motor length ) | mm | 42 |
| 图像 ( Weight ) | Kg | 0.48kg |
这一款机电设备才可以根据客人还要个人定制。
The motor can be designed &manufactured with customized request.
