洽谈协同工作| 特征（Characteristic） | 参数(Parameter) | ||
| 编号规则器示例(Encoder type) | 1、光电科技简码器 Optical encoder2、磁简码器 Magnetic encoder3、逆转低压变压器Resolver注：很多种分辩率供选择择，增长率式、相比值式供选择择。Note: Multiple resolutions are available；Incremental and absolute values are available. | ||
| 径向装载(Max radial force ) | 115N@20mm from the flange | 情况下基本前提Environmental conditions | 运用前提室内温度： -20℃~ +40℃；Temperature: -20℃~ +40℃应用情况发生环境湿度：≤90%RH（无凝露）；Relative humidity: ≤90%RH(No dewing)平衡装置现状：久别腐蚀、可燃性气态，油滴，尘土，海拔有≤1000m(1000~4000m，降额运用)；Installation environment: Far away active gas,Combustible gas, oil drop, ash.altitude≤1000m(1000~4000m，Derating use)；数据库具体情况：-20℃~ +60℃，≤85%RH（无凝露）。Storage Condition: -20℃~ +60℃，≤85%RH(No dewing). |
| 轴径电动机扭矩(Max axial force ) | 45N | ||
| 绝缘性官阶(Insulation Class) | B | ||
| 防火品阶(Protection level) | IP30 | ||
| 模块(Unit) | FL57SVA02 | FL57SVA03 | FL57SVA04 | |
| 更多端电压(Rated voltage) | VDC | 36 | 36 | 36 |
| 木制托盘转速比(Rated speed) | RPM | 3000 | 3000 | 3000 |
| 额外的惯量(Rated torque) | N·m | 0.3 | 0.45 | 0.6 |
| 三倍瞬时电流(Rated current) | A | 94 | 141 | 188 |
| 满载速比(no load speed) | RPM | 4400 | 4400 | 4400 |
| 阀值传动比(Peak torque) | N·m | 0.9 | 1.35 | 1.8 |
| 阀值电流大小(Peak current) | A | 12.6 | 16.2 | 22.5 |
| 内阻(Line to line resistance) | Ω | 1.2 | 0.8 | 0.5 |
| 电感(Line to line inductance) | mH | 1.2 | 0.8 | 0.6 |
| 反电势弹性系数(Back EMF) | V/Krpm | 5.6 | 5.6 | 5.7 |
| 电动机扭矩公式(Torque constant) | Nm/A | 0.075 | 0.075 | 0.08 |
| 极数(Number of poles) | 8 | |||
| 编写代码器(Encoder) | CPR | 1000 | ||
| 移动惯量(Rotor inertia) | g.cm2 | 210 | 320 | 430 |
| 机壳时间 (Motor length) L | mm | 76 | 96 | 116 |
| 净重(Weight) | Kg | 0.8 | 1.0 | 1.2 |
| 编号No. | 引出来线色泽Lead Color | 引出来线形号Lead Gauge | 效果Function | 声明函Description |
| 1 | 红灰黑色(Red/White) | CableAWG26 | GND | Signal Power negative |
| 2 | 洁白( Red) | VCC:+5VDC | Signal Power positive | |
| 3 | 颜色(Blue) | EA- | Two-channel differential signal (Three-channel differential signal can be provided). | |
| 4 | 蓝玄色(Blue/Black) | EA+ | ||
| 5 | 玄色(Black) | EB- | ||
| 6 | 黑粉色(Black/White) | EB+ | ||
| 7 | 棕红色(Brown) | 霍尔HALL A | ||
| 8 | 蓝绿色(Orange) | 霍尔HALL B | ||
| 9 | 黄绿色(Yellow) | 霍尔HALL C | ||
| 1 | 米黄色(Yellow) | CableAWG18 | U相(Phase U) | |
| 2 | 白(Red) | V相(Phase V) | ||
| 3 | 玄色(Black) | W相(Phase W) |
新款上市机械设备就能假设按照企业还要设计。
The motor can be designed &manufactured with customized request.
| FL57SVA02-E1 | 185.25 KB |
|
| FL57SVA03-E1 | 185.87 KB |
|
| FL57SVA04-E1-02 | 185.99 KB |
|
