机电工程轴径

Motor Shaft   diameter

支持轴径4mm,5mm,6mm,6.35mm

Suitable for shaft   diameter 4mm,5mm,6mm,6.35mm

储存热度 Storage Temperature

-40℃～85℃

保举每日任务具体情况

Environmental   conditions

场地Application

无冲刷性，易然，易爆，导电性甲烷气体，粘液和粉层

No corrosive, flammable, explosive, conductive   gas, liquid and dust.

钓鱼任务温差Temperature

-25℃～80℃

气温Humidity

不不低于85% RH

No more than 85% RH

变电电流 Supply Voltage

5V±0.5V

耗损功率 Current Consumption

≤120mA

差分旌旗灯号导入

Differential   Single Output

5V,GND,Z-,Z+,B-,B+,A-,A+,HW-,HW+,HV-,HV+,HU-,HU+

输人电平体例  Output Level mode

TTL电平 (TTL Compatible)

数据库索引旌旗灯号长宽比

Index Width

1/4T or 1/2T or 1T

 (遵照应该要个性定制 According to the needing)

差分录入电压值

Differential   Output Voltage

高电平填写电阻(VoH) ≥3.4V

High Level   Output (VoH) ≥3.4V

电器设备

运作

Electrical Parameter

低电平輸入相电压(VoL) ≤0.5V

Low Level Output   (VoL) ≤0.5V

差分旌旗灯号发送为主的格局

Differential   Signal Output Format

线驱动软件26C31

Line Drive 26C31

供选择分辩率（单园Unit：线/CPR）

Optional   Resolution

2500线(明确应该要全屋定制)

极对数计算 Pole-pairs

2/4/5对极(可私人定制 According)

HU/HV/HW旌旗灯号相位差

120°

占空比 Duty Cycle

50% ±10%

A/B旌旗灯号相位差 Phase difference

 90°±10°

 相呼应周期

Frequency Response

≤500KHz        注重质量：旌旗灯号周期 = (转数(Rpm)×线数)/60

Note: The signal frequency = (Speed(Rpm) *  number of Lines)/60
