热情接待分工协作| 特征(Characteristic） | 参数(Parameter) | ||
| 代码器范列(Encoder type) | 1、光電商品代码器 Optical encoder2、磁编码查询器 Magnetic encoder3、逆转电抗器Resolver注：好几种分辩率要选，增长式、较为值式要选。Note: Multiple resolutions are available；Incremental and absolute values are available. | ||
| 径向额定负载(Max radial force ) | 28N @ 20mm from the flange | 现状首先Environmental conditions | 采用状态温暖： -20℃~ +40℃；Temperature: -20℃~ +40℃再生利用时候气温：≤90%RH（无凝露）；Relative humidity: ≤90%RH(No dewing)部件状况：阔别多年风蚀、可燃性有害气体，油滴，浮尘，海拔有≤1000m(1000~4000m，降额进行)；Installation environment: Far away active gas,Combustible gas, oil drop, ash.altitude≤1000m(1000~4000m，Derating use)；数据存储前提：-20℃~ +60℃，≤85%RH（无凝露）。Storage Condition: -20℃~ +60℃，≤85%RH(No dewing). |
| 支承负债(Max axial force ) | 10N | ||
| 隔绝官阶(Insulation Class) | Class B | ||
| 个人防护品阶(Protection level) | IP40 | ||
| 象限(Unit) | FL42SVA01 | FL42SVA02 | FL42SVA03 | FL42SVA04 | |
| 三倍相电压(Rated voltage) | VDC | 24 | 24 | 24 | 24 |
| 更多带速(Rated speed) | RPM | 5000 | 5000 | 5000 | 5000 |
| 超额惯量(Rated torque) | N·m | 0.0625 | 0.125 | 0.185 | 0.25 |
| 三倍电流量(Rated current) | A | 2.1 | 4 | 6 | 8 |
| 负载转数(no load speed) | RPM | 7600 | 7400 | 7300 | 7400 |
| 基线力矩(Peak torque) | N·m | 0.19 | 0.38 | 0.56 | 0.75 |
| 顶值感应电流(Peak current) | A | 6.25 | 12 | 18 | 24 |
| 电容(Line to line resistance) | Ω | 1.15 | 0.5 | 0.28 | 0.25 |
| 电感(Line to line inductance) | mH | 1.75 | 0.9 | 0.51 | 0.38 |
| 反电势比率(Back EMF) | V/Krpm | 2.23 | 2.3 | 2.32 | 2.28 |
| 传动比因子(Torque constant) | Nm/A | 0.03 | 0.031 | 0.031 | 0.031 |
| 极数(Number of poles) | 8 | 8 | 8 | 8 | |
| 代码器(Encoder) | CPR | 1000 | 1000 | 1000 | 1000 |
| 跳出惯量(Rotor inertia) | g.cm2 | 24 | 48 | 72 | 96 |
| 车身间距(Motor length) L | mm | 61.3 | 81.3 | 101.3 | 121.3 |
| 份量(Weight) | Kg | 0.3 | 0.45 | 0.65 | 0.8 |
| 序号顺序No. | 引入线色彩的运用Lead Color | 找出线应用Lead Gauge | 药理作用Function | 声明范文Description |
| 1 | 红白(Red/White) | Cable AWG26 | GND | Signal Power negative |
| 2 | 黄白色( Red) | VCC:+5VDC | Signal Power positive | |
| 3 | 红色(Blue) | EA- | Two-channel differential signal (Three-channel differential signal can be provided). | |
| 4 | 蓝玄色(Blue/Black) | EA+ | ||
| 5 | 玄色(Black) | EB- | ||
| 6 | 黑粉色(Black/White) | EB+ | ||
| 7 | 深褐色(Brown) | 霍尔HALL A | ||
| 8 | 橘色(Orange) | 霍尔HALL B | ||
| 9 | 金色(Yellow) | 霍尔HALL C | ||
| 1 | 茶色(Yellow) | Cable AWG18 | U相(Phase U) | |
| 2 | 白色的(Red) | V相(Phase V) | ||
| 3 | 玄色(Black) | W相(Phase W) |
这一款有限公司并能明确业主需要全屋定制。
The motor can be designed &manufactured with customized request.
| FL42SVA01 | 281.49 KB |
|
| FL42SVA02 | 281.19 KB |
|
| FL42SVA03 | 283.29 KB |
|
| FL42SVA04 | 283.47 KB |
|
